Hot Runner Mould Heaters
Applications of Hot Runner Mould Heater :
Hot Sprue Bushings
Sealing Bars & Dies
Hot Metal Forming Punches
Features of Hot Runner Mould Heater :
Fiberglass, Stainless-steel Armour & Stainless-steel Braid Lead Options
A wide range of lengths are available up to 2000mm.
Optional built-in-type 'J' Thermocouple.
Flat, Square or Round profiles.
|
Sheath Material
|
High-Nickel Alloy ( CrNi-Stell, Material No: 1.4541 )
|
|
Heating Conductor
|
Nickel / Chromium ( NiCr 8020, Material No: 2.4869 )
|
|
Insulation Material
|
Highly Compressed magnesium Oxide ( MgO )
|
|
Voltage Range
|
240-250V ac
|
|
Leakage Current
|
<0.5mA
|
|
Insulation Resistance
|
Approx. 10MOhms
|
|
Wattage tolerance
|
+/- 10%
|
|
Thermocouple
|
Type' 'J' Fe/CuNi
|
|
Standard Cold Length
|
2.2 x 4.2 = 90mm, 3.2 x 3.2 = 100mm, 3mm dia = 150mm
|
|
Max. Operating Temp.
|
5000
|
|
Min. Forming Radius
|
Flat : 2.2 x 4.2 = 5.00mm, 1.8 x 3.2 = 4.00mm
Square : All sizes = 6.00mm Round : 4.0 = 6.0mm, 3.0 = 4.00mm |
Cross Sections
Coils are available with flat, Square and round cross-sections. The dimensions are as follows :
| Flat | 2.2 x 4.2mm | 1.8 x 3.2mm |
| Square | 3.0 x 3.0mm | 3.2 x 3.2mm |
| Round | 4.0mmdia | 3.0mmdia |
Note : Size marked with an * are the most popular and kept in stock. Most stock items have integrated thermocouples.
| Size | 3.3 | 3.83 | 3.3 x 3.3 | 2.2 x 3.8 |
| Cross Section | o | o | ||
| Cold Zone | 3.3 | 3.8 | 3.8 | 3.3 |
| Adapter Diameter | 7.5 | 7.5 | 7.5 | 7.5 |
| Adapter Length | 32 | 32 | 32 | 32 |
| Crimp Diameter | 9.5 | 9.5 | 9.5 | 9.5 |
| Maximum Length | 2000 | 3000 | 3000 | 2000 |
| Maximum Current | 5A | 5A | 5A | 5A |
| Minimum Diameter | 8 | 10< | 8< | 6 |
